Solution Center

Central hub for creating, managing, and launching FrameworX solutions.

Modules → Solution Center | Tutorial | How-to Guide | Reference

Solution Center is where you create, open, and manage solutions. It handles licensing, connects to local or remote servers, and launches Designer for configuration or Runtime for execution.

All solutions are stored as single .dbsln files containing the complete configuration.

Solution Center Workspace

It is the unified environment to create, open, run and manage solutions

FrameworX Solution Center

Server Information >

Your License >

About FrameworX >

Selected Solution: <solution name>

New Edit View Run Manage

Select a solution

Workspace

Solutions List

Key Concepts

Term	Description	Details
Solution File (.dbsln)	Encrypted SQL database containing all configurations	Single file contains tags, displays, scripts, all modules
Solution List	Central display of available solutions	Shows status, preview images, organization folders
Server Connection	Access to local or remote solutions	Via TWebServices (port 10108)
Execution Profiles	Runtime modes with different security levels	Development, Validation, or Production
Multi-User Access	Concurrent engineering capability	Multiple users can work on same solution
Click-Once Deployment	Browser-based Designer launch	No local installation required

What Solution Center Does

Solution Management

Solution Execution

System Administration

Create new solutions

Open existing solutions

Upgrade legacy projects

List running solution

Run solutions

Run diagnostics tools

License management

Service configuration

Remote access setup

How It Fits in the Solution Lifecycle

Solution Center is the first touchpoint in the Solution Lifecycle:

Solution Center ← You are here (Create and manage)
Designer - Configure your solution
Runtime - Execute and monitor

It serves as both the starting point for new solutions and the ongoing management hub throughout the solution's lifecycle.

Typical Workflow

Step	Action	Description	Options
1. Connect	Select server	Choose local or remote server	Local, IP address, domain name
2. Create/Open	Solution selection	New solution or open existing	Blank, template, import, .dbsln file
3. Verify License	Check status	Ensure appropriate license	Development, Runtime, Combined
4. Configure	Launch Designer	Edit solution configuration	Exclusive or multi-user mode
5. Select Profile	Set execution mode	Choose runtime behavior	Development, Validation, Production
6. Execute	Start Runtime	Run the solution	With selected profile and clients

Feature Highlights

Solution Organization

Single-file architecture - All configurations in one .dbsln file
Preview images - MainPage display shown as thumbnail
Multiple views - List, Card, or Table display options
Search and filter - Quick solution location
Folder organization - Logical grouping of solutions

Collaboration Features

Multi-user support - Concurrent engineering on same solution
Server-based access - Centralized solution repository
Access control - Security keys for remote connections
Version management - Built-in backup and restore
Legacy migration - Upgrade path from .tProj files (v9.1+)

License Management

Unified licensing - Single point for all operations
License types - Development, Runtime, Combined, Trial
Feature visibility - Tag count, user limits, I/O points
Remote activation - Online and offline activation
Expiration monitoring - Proactive renewal alerts

Deployment Flexibility

Click-Once technology - Zero-installation Designer access
Cross-platform - Windows desktop and web browser
Remote management - Full functionality over network
Template library - Industry-specific starting points
Automated startup - Solution auto-launch configuration

Solution Center Links

Central hub for creating, managing, and launching FrameworX solutions with multi-user collaboration support.
